3D Infrared Thermal Imager Analyzer

The PCBA thermal imaging analysis system is a product that uses infrared thermal imaging technology in the field of circuit board troubleshooting. This product can assist engineers to quickly locate defect in PCBAs, such as short circuits, current leakage etc., to improve R&D and troubleshooting's efficiency.

Software :
Suitable for Windows system, recommended to use Win10 or Win11, It is not recommended Win7 or other systems

Specifications:

• Resolution:256x192 pixel
• Frame frequency:25Hz
• The range of temperature measurement:-20°C~+150°C(4F~+302°F)
• View field angle of the lens:56°x42°
• The distance of temperature measurement:30mm -150mm
• The device interface:USB Type C
• Storage format of the pictures:JPG
• Storage format of the videos: MP4
• The input voltage:    DC 5V
• The temperature range for storage    :-20°C~60°C
• Working temperature:0C~50°C
• The humidity:95% relative humidity
