DC-DC Boost Converter, 12V/24V to 48V 5A Boost Transformer

DC/DC 12V BOOST to 48V5A Voltage Transformer

Parameters

• Name：Voltage Boost Supply Converter

• Input Voltage: 12V DC

• Output voltage: 48V DC

• Output power:240W Max

• Output current: 5A

• Working temperature: -25℃ ～ +65℃

• Storage temperature：-40℃ ～ +85℃

Feature

• Converts 12V/24V DC input to a stabilized 48V output (up to 5A), delivering 240W of continuous power with 92% efficiency - ideal for power-hungry equipment

• Aluminum waterproof housing ensures stable operation even in high-temperature environments (-25°C to +65°C)

• Precise output monitoring to prevent under/over voltage damage to connected equipment.

• Integrated overvoltage, overcurrent, short-circuit and thermal protection protects both the converter and the device.

• Well suited for golf carts, solar power systems, CCTV cameras, motorized scooters, industrial equipment and other 48V DC devices.
